Настенный генератор горячего воздуха Lodos 80

газовыйдля применения в сельском хозяйстве

Daygas combines efficient, economical, high-quality, and functional products that place great emphasis on innovation, research, and development, thereby saving energy in the heating sector for end users.Quiet operation.Fast start-up.Cooling mode.Low emissions.Low energy consumption.High safety level.System of safety gas valves.Step and image notification of malfunction on the display screen.Increased efficiency thanks to specially designed boiler construction.Possibility of remote-controlled 5-step or thermostatic mode.Technical Specifications:Power80kWGas consumptionNG 7.55m³/h / LPG 5.60kg/hDimensions790h / 1057L / 842wWeightNet 103.25kg / Gross 124.04kgOperating pressureNG 21-55mbar / LPG 32-55mbarHeating area, m²min 375m² / avg 450m² / max 540m²Heating volume, m³min 890m³ / avg 1360m³ / max 1600m³Noise level in empty room62 d-BANoise level in working room50 d-BAAir output m³6900m³Electrical connection (EU):190-260 V / 50-60 HzGas connectionG ¾’’Product Features:Uniform heat distribution.Compact design.Lodos hot air generators with advanced burner technology emit minimal exhaust gas and directly heat the area where the event is held. The heat generated in the ribbed heat exchangers with increased efficiency is transferred directly to the environment via an axial fan, ensuring the most homogeneous heat distribution.Daygas Lodos hot air generators provide thermal energy from natural gas or liquefied petroleum gas by supplying hot air directly or through air ducts to the heated environment using a built-in fan. They offer high efficiency and low energy consumption thanks to their specially designed boiler construction. This product has the lowest noise level during operation due to its specially designed boiler and body construction. Recommended for use in closed spaces with ceiling heights not exceeding 5 m for more efficient and uniform heating.Operating Modes:Possibility of operation in hermetic and semi-hermetic versions.All electrical components are made of high-temperature-resistant, non-flammable silicone cables.All metal parts are made of high-temperature-resistant, durable aluminum-silicon alloy.Control Elements:Remote control.Integration via control board.Pako manual control switch.Automatic control with thermostat switching.Integration into automation system (SCADA control).Control Panel Features:Password protection.Heat saving mode.Computer communication port.Graphic LCD screen 128 x 64.Anti-freeze protection function.Programmable 24/7 function.Automatic and manual control options.Possibility to connect an external temperature sensor.Control of up to 8 independent zones and 32 devices in total.Analog Room Thermostat: The Daygas analog room thermostat turns off when the set temperature is reached, automatically switching the device off. When the ambient temperature drops below the set value, the device automatically turns on at maximum level, thus saving fuel.Temperature Sensor: The Daygas temperature sensor provides fuel savings by reducing the modulation value of the device depending on weather conditions. When the ambient temperature reaches the desired value, the device automatically turns off, and when the temperature drops below the desired value, it automatically sets the most suitable temperature for the environment.Anti-freeze mode.Smooth control capability.Temperature adjustment via device.Manual Control with Pako Switch: Stepwise manual control via Pako switch can be provided where there is no control panel or it is not needed, allowing local control at the required level.Remote Control: Daygas remote controls have 3 buttons and simple functions, offering easy use. All Daygas products can be controlled remotely with a single remote.Integration into building automation systems (BMS) via Modbus protocol through RS485 port (internal). If no BMS is available, device control can be performed via HMI touch panel or PC locally. Full automation from the center is possible.In BMS System:Device operation scheduling for specified days and hours.Regional or individual stepwise and modulation control of heaters.Viewing error codes from devices in the system, identifying which device has a problem, and saving them in memory.Functional control elements such as instant, daily, weekly, or monthly fuel consumption monitoring.Key Features / Technical Specifications:Power: 80kWGas consumption: NG 7.55m³/h / LPG 5.60kg/hDimensions: 790h / 1057L / 842wWeight: Net 103.25kg / Gross 124.04kgOperating pressure: NG 21-55mbar / LPG 32-55mbarHeating area: min 375m² / avg 450m² / max 540m²Heating volume: min 890m³ / avg 1360m³ / max 1600m³Noise level (empty room): 62 d-BANoise level (working room): 50 d-BAAir output: 6900m³Electrical connection (EU): 190-260 V / 50-60 HzGas connection: G ¾’’
